Orion XTR Series 4 Channel Amplifier, 750W RMS
$299.95
Skip to product information
Orion XTR Series 4 Channel Amplifier, 750W RMS
$299.95
Orion XTR Series 4 Channel Amplifier, 750W RMS
- Channels: 4 Channel
- RMS Power: 750W
- Stable to: 2 Ohm
- Amplifier Class: A/B
- SKU: XTR7504
Specifications
- 750 Watts RMS
- 4 x 188 Watts RMS @ 2 Ohms
- 4 x 135 Watts RMS @ 4 Ohms
- 2 x 375 Watts RMS @ 4 Ohms Bridged
- CEA-2006 compliant
- Class A/B
- DIM (W X H X L) 9.3″ x 2.75″ x 11.5″
- Fuses: 3 x 40A (ATC Fuses)
- 2 Ohm Stable
- Frequency Response: 20Hz – 35kHz
- Linear Bandwidth 20Hz to 65kHz +/- 3 dB
- High Pass Crossover: 50 – 5kHz
- Low Pass Crossover: 50 – 400Hz
- Supply Voltage: 9 – 16V
- Amplifier Efficiency: >60%
- Damping Factor: 100dB
- Signal to Noise Ratio: >95dB
- T.H.D. & Noise: 0.5%
- Phase Shift: 0 – 180
- Bass Boost: 0-18dB Variable
- Variable Input Level Control: 0.2V – 6.0V
